Wound String (Yarn) Filter Cartridge

Get a Price/Quote

MOQ : 01 Piece

Wound String (Yarn) Filter Cartridge Specification

Pressure
Max 6 bar

Filter Rating
1, 5, 10, 20, 50 Microns

Sealing
Thermally Bonded, Optional O-ring

Inlet Diameter
Standard 28 mm, Customizable

Outlet Diameter
Standard 28 mm, Customizable

Shape
Cylindrical

Filter Media
Yarn (Polypropylene)

Pore Size
1-100 Microns

Product Type
Wound String (Yarn) Filter Cartridge

Material
Polypropylene (PP) Yarn or Cotton

Type
Filter Cartridge

Cartridge Style
Wound String

Diameter
2.5 inch (Standard), 4.5 inch (Big Blue)

Efficiency
Up to 99%

Application
Water Filtration, Chemical Filtration, Food and Beverage, Pharmaceutical, Industrial Processes

Wound String (Yarn) Filter Cartridge Trade Information

Minimum Order Quantity
01 Piece

Payment Terms
Letter of Credit (L/C), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Cheque

Supply Ability
200 Pieces Per Year

Delivery Time
200 Years

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
WOODEN CHARGE

Main Export Market(s)
Australia, North America, Eastern Europe, Middle East, Africa, Central America, South America, Western Europe, Asia

Main Domestic Market
All India

Certifications
ISO 9001-2008 MSME

About Wound String (Yarn) Filter Cartridge

Wound String (Yarn) Filter Cartridge

Product Details
Wound type Filter Cartridge are good depth filter elements for minimum viscous liquids having low solids contents. An excellent winding method is used for the depth filtration purpose. This cartridges gives you High flow rate and good solid loading capacity.

Available Different Size

Length : 10", 20", 30", 40"

Diameter : 2.5", 4"

Micron Size : 1, 5, 10, 20, 50, 100

Technical Data
Maximum operating Temperature : Depending on the material of Wounding. The differential Pressure : 0.1 bar (1.5 psi) Maximum Pressure Drop : : 2 bar (30 psi)

Different Make of Construction Winding Material Core Material Polypropylene Polypropylene Cotton S.S. 304 Polyester S.S. 316 Nylon G.I. Glass Fiber

Suitable Application

Potable Liquids, Water
Alkalizes Solvents
Pre - Filtration for R.O.Oils
Inorganic Acids Organic Acids

Reliable Filtration for Diverse Applications

This wound string filter cartridge is engineered to ensure effective filtration for a wide array of uses. Whether applied in water purification, chemical processing, food and beverage preparation, or pharmaceutical manufacturing, it delivers consistent results thanks to its adaptable design and broad chemical compatibility (pH range 1-13). Its high dirt retention, low pressure drop, and up to 99% efficiency make it an ideal solution for industrial and commercial sectors alike.

Customizable Configuration and Easy Integration

The cartridge is offered in several lengths and diameters to fit standard and Big Blue housings. With customizable core materials and optional O-rings for enhanced sealing, it integrates seamlessly into existing systems. Double open end (DOE) and single open end (SOE) designs, alongside thermally bonded sealing, provide installation flexibility and reliability. Suitable for dealers, distributors, exporters, fabricators, and manufacturers across India.

FAQs of Wound String (Yarn) Filter Cartridge:

Q: How does the wound string filter cartridge function in filtration processes?

A: The filter operates by trapping particulates and contaminants within its layered yarn structure as fluid passes through. Its high dirt holding capacity ensures prolonged service life and reduced maintenance, delivering efficient particulate removal for various applications.

Q: What sizes, micron ratings, and materials are available for this cartridge?

A: Cartridges are available in 5, 10, 20, 30, and 40 inch lengths, with diameters of 2.5 inch (standard) and 4.5 inch (Big Blue). Micron ratings range from 1 to 50 microns, and core materials include polypropylene, stainless steel, and tin-plated steel. The filter media can be polypropylene yarn or cotton.

Q: When should I replace the wound string filter cartridge?

A: Replacement depends on pressure drop or visual inspection for clogging. Typically, it should be replaced when a notable decrease in flow rate occurs, or as recommended by your systems maintenance schedule. Since the cartridge is disposable, reuse is not advised.

Q: Where can this filter cartridge be used and what housings is it compatible with?

A: The cartridge fits standard filter housings and Big Blue filter housings, making it suitable for a variety of systems. Common uses are in water treatment units, industrial and chemical processing lines, food and beverage plants, and pharmaceutical facilities.

Q: What are the key benefits of using this filter cartridge in my system?

A: This cartridge provides high filtration efficiency (up to 99%), excellent chemical resistance, and low operational pressure drop. Its robust construction ensures longevity, and it is compatible with a wide range of liquids across various industrial, commercial, and municipal water treatment applications.

Q: How do I select the right wound string filter cartridge for my needs?

A: Consider your filtration application, required micron rating, chemical compatibility (pH), maximum operating temperature, and the housing type. Choose the length and diameter suitable for your filter housing, and select the core material based on fluid compatibility.
