Spun Filter Cartridge

Get a Price/Quote

MOQ : 01 Piece

Spun Filter Cartridge Specification

Shape
Cylindrical

Pore Size
5 Micron

Outlet Diameter
Standard 1 inch

Sealing
Flat Gasket

Filter Media
Polypropylene Fiber

Inlet Diameter
Standard 1 inch

Filter Rating
5 Micron

Pressure
Maximum rated pressure: 4 Bar

Product Type
Spun Filter Cartridge

Material
Polypropylene

Type
Filter Cartridge

Cartridge Style
Spun Bond

Diameter
2.5 inch

Efficiency
Up to 98%

Application
Water Filtration, Chemical Filtration, Pre-filtration for RO Systems

Spun Filter Cartridge Trade Information

Minimum Order Quantity
01 Piece

Payment Terms
Letter of Credit (L/C), Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Cheque

Supply Ability
200 Pieces Per Year

Delivery Time
200 Years

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
WOODEN CHARGE

Main Export Market(s)
Australia, North America, Eastern Europe, Middle East, Western Europe, Africa, Central America, South America, Asia

Main Domestic Market
All India

Certifications
ISO 9001-2008 MSME

About Spun Filter Cartridge

Spun Filter Cartridge

Product Details After the latest research & development in the nominal rated Spun Filter Cartridges , to give the excellent life and best performance from the controlled manufacturing process. Made by 100% FDA Procedure with 100 % FDA approved Polypropylene Fibber. Made with the latest Technology and in the Fiber to give the best performance with dirt holding capacity with good flow.

Available Different Size

Size : 10", 20", 30", 40", 60"
Diameter : 2.5", 4"
Micron : 1, 5, 10, 20, 50, 100

Technical Data 100 % polypropylene fiber media and pure polypropylene core. The Cartridge structure features excellent depth filtration due to good porosity. Maximum operating Temperature is 70C . The nominal outer diameter is 63 mm and inner diameter is 27 mm. The Pore size is available : 1 , 5 , 10 , 20 , 50 & 100 m. The Standard Length is available : 10" , 20" , 30" , 40". Generally maximum operating pressure is 1.70bar (24psi).

General Application

Pharmaceutical Industry : Washing Machine , R.O. Pre - Filtration, Small Volume& Large Volume Parental
Color & Dyes Industry : R.O. Pre - Filtration , Dyes Filtration, Color Filtration
Chemical Industry : Chemical , Solvent , Water Filtration
Water Treatment Industry : Pre - Treatment for R.O., Mineral Water Plant , Resin trap
Textile industry : Pre - Treatment for R.O. , Production water

Engineered for Precision Filtration

This Spun Filter Cartridge features a robust polypropylene fiber media and a spun bond style, offering superior dirt-trapping efficiency for water and chemical pre-filtration. With a 5-micron rating, it effectively protects downstream RO membranes and other filter stages, ensuring both longevity and consistent water quality in diverse applications.

Versatile and Easy to Install

Designed to fit standard 10-inch filter housings with 1-inch inlet and outlet diameters, this cartridge provides seamless installation for various water filtration systems. Its lightweight, compact design (150g, 2.5-inch diameter) makes it suitable for use by manufacturers, dealers, and end-users in RO plants or water treatment setups.

FAQs of Spun Filter Cartridge:

Q: How do I install the 10 Inch Spun Filter Cartridge in my water filtration system?

A: To install, simply place the cartridge inside a standard 10-inch filter housing with 1-inch inlet and outlet ports. Ensure the flat gasket is seated properly for a secure, leak-free fit before closing the housing.

Q: What is the typical usage of this filter cartridge in RO systems?

A: This spun filter cartridge is primarily used as a pre-filtration stage in reverse osmosis (RO) systems, capturing sediment, dirt, and particles down to 5 microns. This helps protect sensitive RO membranes and prolongs system life.

Q: When should the Spun Filter Cartridge be replaced?

A: Cartridge replacement frequency depends on feed water quality and the flow rate, but it is generally recommended to change the filter every 3 to 6 months or when a noticeable drop in flow rate or water quality is observed.

Q: Where can this filter cartridge be used besides water filtration?

A: In addition to water filtration, this cartridge is suitable for chemical filtration, pre-treatment in industrial applications, and any process requiring particulate removal up to 5 microns. Its robust polypropylene construction withstands a variety of liquid streams.

Q: What are the benefits of using a spun bond polypropylene cartridge?

A: The spun bond polypropylene design offers high filtration efficiency (up to 98%), resistance to chemicals, and durability at temperatures up to 60C and pressures up to 4 bar. It reduces system maintenance and provides reliable contaminant removal.

Q: How does the flat gasket sealing enhance the filtration process?

A: The flat gasket provides a tight, reliable seal in standard housings, preventing bypass and ensuring all fluid passes through the filter media for maximum contaminant removal.
