Metal Working Fluids Micron Filters

Get a Price/Quote

Metal Working Fluids Micron Filters Specification

Pore Size
1, 5, 10, 25, 50 Micron

Filter Media
High-Filtration Synthetic Media

Inlet Diameter
Custom (Standard: 1-2 Inch)

Sealing
Silicone/Rubber Gasket

Pressure
Max 7 Bar

Outlet Diameter
Custom (Standard: 1-2 Inch)

Filter Rating
1 to 50 Micron

Shape
Cylindrical

Product Type
Industrial Filtration Cartridge

Material
Polypropylene / Glass Fiber

Type
Micron Filter

Cartridge Style
Replaceable Cartridge

Diameter
Customizable (Standard: 60-120 mm)

Efficiency
Up to 99.9%

Application
Metalworking Fluid Filtration

End Cap Material
Polypropylene

Usage
CNC, Grinding, Milling, and Machining Applications

Length
250 mm, 500 mm, 1000 mm (Custom Sizes Available)

Max Operating Temperature
60°C

Color
White

Compliance
Meets Industry Filtration Standards

pH Range
3-11

Flow Rate
Up to 5000 LPH (Depending on Model)

Metal Working Fluids Micron Filters Trade Information

FOB Port
yes

Payment Terms
Cash Against Delivery (CAD), Cash on Delivery (COD), Letter of Credit (L/C), Paypal, Western Union, Telegraphic Transfer (T/T), Cash in Advance (CID), Cheque, Cash Advance (CA)

Supply Ability
1000 Per Year

Delivery Time
3 Week

Sample Policy
Free samples available with shipping and taxes paid by the buyer

Packaging Details
PACKING, WOODEN BOX

Main Export Market(s)
Australia, North America, South America, Eastern Europe, Western Europe, Middle East, Africa, Asia, Central America

Main Domestic Market
All India

Certifications
ISO 9001 : 2015

About Metal Working Fluids Micron Filters

Metal Working Fluids Micron Filters

Applications:

Food & beverages
Dyes & Intermediates
RO Pre filtration
Pharmaceuticals
Bore Well water
Processing Chemicals
Dairy Petroleum Derivatives
Paints & Inks
Coolants
Water Treatment
Features :

Accommodates for 10",20,30,40 Long Filter cartridges

Flow rate up to 2000 m3/hr
Provide custom design services
Housings are permanently piped
All Housings Made from SS 316L , SS 316 & SS304 Are Mirror polished & electro polished to Resist Adhesion of Dirt and Scale
Low pressure drop
High dirt holding capacity
Zero hold up design
Custom design services
Jacketed / Duplex / Triplex Cartridge filter Unit designs are available
High Temperature & High Pressure Design are available
Easy to Clean
Permanently Piped Housing Are Opened Without Special Tools and Without Disturbing the Piping
Machined Cover gasket Groove Provide Positive O-ring Sealing
Carbon Steel Housing are painted externally & Internally Epoxy Coated
End Connections for ¾" Through 24" pipe
Threaded Center Posts or V Posts
Quick Opening Tri Clovers Design
Easy to operate & Low maintenance
ASME Code stamp available
Suitable for Double Open End (DOE), Code 7 & 222 O Ring Type Filter Cartridge
Positive Sealing Arrangement to avoid Bypassing

Technical Specifications:

Material of construction: PP , PVC , ACRALIC

Sizes Cartridge Filter Housings Suitable for: 1Nos To 500 Nos. Of Cartridges in Single Housing, 2, 5, 4, 6 & 8

Diameter of Cartridge, 10 to 60 Long Filter cartridge, Flow Rate

Capacity: Up to 2000 m3 /hr

Gasket / O Ring Material: Neoprene, Nitrile, Silicone, Viton, Buna N, EPDM, PTFE

Cartridge Filter Housing Suitable for Filter cartridges of: Double Open End (DOE) Type, Code 7 (226 O Ring) Design, Code 3 (222 O Ring) Design, NPT Threaded Connection Type, End Connections Available, NPT / BSP Threaded, Flanged Table E / Table F, ANSI B 16.5, ASA 150 RF, DIN Standard, Tri Clover Adaptors and SMS /Dairy End Connection

Exceptional Filtration Performance

Achieve consistent results in metalworking with micron filters offering up to 99.9% filtration efficiency. The synthetic media, with pore sizes from 1 to 50 microns, ensures removal of contaminants and prolongs the lifespan of your machinery and fluids. Suitable for heavy-duty environments, these filters are trusted by dealers, exporters, and manufacturers alike.

Versatile & Customizable Designs

Choose from lengths of 250 mm, 500 mm, or 1000 mm, and diameters from 60 mm up to 120 mm for a perfect fit in your filtration system. Both inlet and outlet diameters can be tailored, ensuring seamless integration. The robust polypropylene end caps and silicone/rubber gaskets guarantee reliable sealing across various installation conditions.

Reliable Compliance & Easy Replacement

Rest assured knowing your filtration system meets industry standards for performance and safety. The cartridge style enables straightforward replacement, minimizing downtime. Whether you are a retailer, supplier, or direct user, these filters deliver consistent, high-quality filtration for all types of machining fluids.

FAQ's of Metal Working Fluids Micron Filters:

Q: How do I choose the correct pore size for my metalworking fluid application?

A: Select the pore size-1, 5, 10, 25, or 50 micron-based on the level of particle removal required. Finer pores (1-5 micron) are ideal for sensitive CNC and grinding processes, while larger sizes can be used in less critical applications. Consulting your machine's manual or a manufacturer's guide can help determine the optimal choice.

Q: What is the process for replacing the filter cartridge?

A: First, depressurize the filtration system and safely access the filter housing. Remove the used cartridge by loosening it from the end caps. Insert the new filter ensuring the silicone/rubber gasket is properly sealed, then reassemble and pressurize the unit. Regular replacement maintains high filtration efficiency and process safety.

Q: When should I replace the micron filter in my system?

A: Monitor differential pressure across the filter. When it approaches the maximum recommended level or when you notice reduced flow rate, replace the filter cartridge immediately. Regular replacement schedules, aligned with operational hours and fluid contamination levels, are advised for continuous optimal performance.

Q: Where can these metal working fluid filters be used?

A: These filters are suitable for a variety of environments including CNC workshops, grinding stations, milling setups, and all machining facilities requiring precise metalworking fluid filtration. Their adaptable sizing and robust construction make them popular among manufacturers, exporters, suppliers, and fabricators across India.

Q: What are the benefits of using high-filtration synthetic media in these filters?

A: High-filtration synthetic media, like polypropylene and glass fiber, provide superior particle retention, chemical compatibility within a wide pH range (3-11), and high durability at operating temperatures up to 60C. This ensures effective filtration, extends fluid and equipment life, and reduces maintenance needs.

Q: How does the filter ensure compliance with industry standards?

A: These filters are engineered to meet recognized industry filtration standards, ensuring reliable performance, consistent quality, and safe operation in industrial processes. They are widely accepted by dealers, distributors, and end users meeting national and international requirements.
