High Speed Tablet Press- Tabxpress-PTX

About High Speed Tablet Press- Tabxpress-PTX

HIGH SPEED TABLET PRESS- TABXPRESS-PTXHigh Speed Single Sided, Central Drive & Pre-Compression Tablet Press GMP ModelApplication & Process :TabXpress-PTX Tablet Press Machine is used for production of simple and precise tablets from powder in Pharmaceutical and relevant Industries.TabXpress-PTX is a high speed single sided central drive Pre compression Rotary Tablet Press suitable for medium batch size production.TabXpress-PTX designed in an effort to exceed the highest cGMP requirement and to ensure the most economical and efficient tablet production. The TabXpress-PTX features a unique ergonomic design for easy to operate, easy to fast changeover, easy to clean with minimum down time. The TabXpress Tablet Press is completely separated into three zones i.e. Tablet Compression zone, Machine service zone and Electrical controls zone. The Optional feature of TabXpress-PTX machine can provide with Touch Screen Operate Interface with PLC Controls, which is mounted in a separate electric controls cabinet.TabXpress PTX Tablet Press is offered in four different models viz. Tooling 26 Stn "D" Type, 32 Stn "B" Type, 40 Stn "BB" Type.
The Machine Ergonomics Design Concept :The TabXpress-PTX has been completely new designed according to the most modern ergonomic aspects. cGMP confirm. Machine's basic construction with separate compression zone and drive zone. Fast Cleaning and Changeover capability. Stainless Steel and Acrylic Glass Surrounding. Easy to Operate and Maintenance.Salient Features : Design is cGMP - Current Good Manufacturing Practices compliance. All contact parts AISI 316 & non contact parts AISI 304. TabXpress- PTX is high speed single sided tablet press with central drive, pre compression and suitable for medium size batch production and offered in three model "D" , "B" & "BB" Tooling. Simple & Convenient Operation, Changeover, Cleanliness, Operator Protection & Ease to Maintenance. Single sided compression with higher output. Pre-Compression System to improve compressibility and tablet Quality. All parameters setting of tablet; like tablet thickness, weight adjustment, Pre-compression Pressure, Main Pressure are provided in front of the machine and outside the compression zone. Tablet parameters can be tuned during operations from outside the tableting zone Easy accessibility for quick cleaning and product changeover. Drive system completely enclosed and sealed off from the pressing zone. Turret Drive is Central Drive from Closed Gearbox, No Gearing on Turret. Electromagnetic Clutch for turret drive. A C Frequency variable drive for Turret Motor and Feeder Motor. Force feeder systems with bottom drive for uniform filling to weight consistency. 3 Pcs. Turret with S.S 316 Die Pot. Auto Lubrication system Upper Punch penetration & Lower Punch scraper seal. S.S. 304 closer at bottom drive zone and acrylic glass surrounding at compression zone.
Optional Features : PLC Controls with HMI Touch screen interface. Powder level sensor for hopper. Start and stop times Rejection and sampling deviceSafety Features : Interlocked upper guard and Overload relay protection. Overload pressure release mechanism. Emergency stop button.________________________________________Technical Specification :Model TabXpress PTX- 26 TabXpress PTX- 32 TabXpress PTX-40No. of Station 26 32 40Type of Tooling D B BBOutput-tablets per Hour 15,600 to 1,09,200 19,200 to 1,34,400 24,000 to 1,68,000Max. Operating Pressure-Main 100 kN 80 kN 80 kNMax. Operating Pressure- Pre-Press 18 kN 18 kN 18 kNMax. Operating pressure 25 mm 16 mm 11 mmDepth of Fill 20.5 mm 17.5 mm 17.5 mmUpper punch penetration 3 to 6 mm 3 to 6 mm 3 to 6 mmTotal Power consumption 6.75 HP / 5.06 kW 6.75 HP / 5.06 kW 6.75 HP / 5.06 kW

Precision Tablet Production at Maximum Speed

The Tabxpress-PTX delivers exceptional output capacity with up to 216,000 tablets per hour, thanks to its 45-station turret design and swift rotation speed. Designed for demanding pharmaceutical environments, it achieves reliable compression and uniform tablet quality through its robust pre-compression system and modular components.


Advanced Automation and User-Friendly Interface

Equipped with a digital control panel and touchscreen HMI, the Tabxpress-PTX makes operation intuitive while supporting real-time error diagnostics. PLC-controlled processes with automated lubrication and integrated safety interlocks provide both efficiency and secure operation throughout production cycles.


Clean, Ergonomic, and Easy to Maintain

A mirror-polished stainless steel surface, enclosed dust extraction vacuum system, and compact footprint ensure high standards of hygiene and adaptability to plant spaces. Maintenance procedures are reduced and streamlined by tool-less changeover and user-friendly access points, minimizing downtime and facilitating consistent output.
