Candle Perfume Filtration System

Get a Price/Quote

Candle Perfume Filtration System Specification

Features
High efficiency filtration, Easy operation, Mess-free filter replacement

Phase
Single and Three Phase

Frequency
50 Hz

Noise Level
Low

Temperature
Up to 60C

Usage & Applications
Perfume, Oil and Liquid Filtration

Type
Candle Perfume Filtration System

Material
Stainless Steel

Capacity
1000 Liters/Hour

Computerized
No

Control Mode
Manual

Voltage
220 V

Power
2.2 kW

Weight (kg)
230 kg

Dimension (L*W*H)
1200 x 800 x 1500 mm

Color
Silver

Mounting
Portable Frame with Castor Wheels

External Finish
Matt finish

Safety Features
Overload and thermal protection

Pump Type
Centrifugal Stainless Steel

Filter Element
Candle Type

Pressure Range
0.2 - 0.6 MPa

Internal Finish
Mirror polish for hygiene

Filtration Accuracy
Up to 1 micron

Inlet/Outlet Size
1.5 inch

Cleaning
CIP (Clean in Place) compatible

Service Support
On-site installation and maintenance

Candle Perfume Filtration System Trade Information

FOB Port
yes

Payment Terms
Cash on Delivery (COD), Letter of Credit (L/C), Western Union, Paypal, Cash Against Delivery (CAD), Telegraphic Transfer (T/T), Cash in Advance (CID), Cheque, Cash Advance (CA)

Supply Ability
100 Per Year

Delivery Time
3 Week

Sample Policy
Free samples available with shipping and taxes paid by the buyer

Packaging Details
PACKING, WOODEN BOX

Main Export Market(s)
Australia, North America, Eastern Europe, Western Europe, Middle East, Central America, South America, Asia, Africa

Main Domestic Market
All India

Certifications
ISO 9001 : 2015

About Candle Perfume Filtration System

Microtech engineering offer offer candle perfume filtration system with candle cleaning system electrical flameproof.

Technical Specifications:

Model
No. Of candles
4 nos
6 nos
Filtering candle
s. S. 316 / 10-20 micron
s. S. 316 / 10-20 micron

Output(ltrs/hr)
800-1500 ltrs/ hr/
2000-3000 ltrs/ hr/

Liquid holding

a0a after full transfer

Thickness of shell
3mm thick

Thick of top- bottom cover

5 mm thick

Length of candle

200 mm

Inlet conical filter

6a dia x s. S. Mash

Process inlet outlet

1a dia hose nipple

Direct use pump connection
1a bsp ball valve / 1 A12 a hose nipple.

Candle cleaning system

1 candle clean at a time

Pump mechanical seal

S. S. 316 Teflon.

Pump motor

2hp / 440 rpm / 3 ph / flame-proof

3 hp / 440 rpm / 3 ph / flame-proof

Air vent- safety valve

A14 BSP.

Drain valve

1a BSP

M. O. C

s. S. 304 l / 316

Finish

Polished to mirror finish.

Salient Features:

All contact parts made out of s. S. 304 l material.

No requirements of any filter pad / filter.
S. S. Candle for crystal clear filtration & long lasting.
Option: - pump can be use separately for water transfer or usually with the filter press.

Exceptional Filtration Performance

Engineered with a candle-type filter element, this perfume filtration system delivers up to 1-micron filtration accuracy, ensuring high purity for sensitive applications such as perfume and oil processing. The mirror-polished internal surface maintains strict hygiene standards, while the advanced centrifugal pump enables consistent and high-capacity operation. This system efficiently removes impurities, protecting product integrity and maximizing end-product quality.

Built for Hygienic, Easy Operation

The filtration unit features a mirror polish inside and a matt finish outside for easy cleaning and enhanced hygiene. Its CIP (Clean in Place) compatibility means you don't have to disassemble parts for cleaning, saving time and effort. Mess-free filter replacement and a user-friendly manual control mode make everyday operation straightforward and reliable. Overload and thermal protection safeguards the unit during intensive use.

Portable and Reliable for Diverse Needs

Mounted on a sturdy portable frame with castor wheels, this system can be easily relocated within your production area. Whether you are a manufacturer, supplier, or distributor in India, the unit's versatility and robust construction suit a range of filtration needs, supporting both single and three-phase operations. On-site installation and maintenance services offer peace of mind for long-term performance.

FAQ's of Candle Perfume Filtration System:

Q: How does the Candle Perfume Filtration System achieve high filtration accuracy?

A: This system utilizes a candle-type filter element capable of removing particles down to 1 micron, ensuring exceptionally fine filtration for perfumes, oils, and similar liquids.

Q: What is the process for cleaning the filtration system?

A: The filtration system is CIP (Clean in Place) compatible, meaning you can clean the internal components without dismantling the unit, streamlining maintenance and maintaining hygiene.

Q: Where can the Candle Perfume Filtration System be used?

A: It is suitable for use in perfume, oil, and liquid processing industries, including manufacturing facilities, export units, and laboratories throughout India.

Q: When should the filter element be replaced?

A: The filter should be replaced as per the operation manual's recommendations or whenever you notice reduced filtration efficiency or increased pressure drop, ensuring optimal system performance.

Q: What are the key benefits of using this system?

A: Users benefit from high-efficiency filtration, easy and hygienic operation, mess-free filter replacement, portable design, advanced safety features, and comprehensive on-site service support.

Q: How do I operate and control the filtration system?

A: Operation is manual and straightforward, with all controls easily accessible. No computerized controls are needed, making training simple and minimizing the risk of operator error.

Q: Is installation and support available for this unit?

A: Yes, on-site installation and maintenance support are provided by the manufacturer or authorized dealer across India, ensuring seamless setup and ongoing service.
