Silicon Sealant Making Machine

Get a Price/Quote

Silicon Sealant Making Machine Specification

Usage & Applications
For manufacturing silicone sealant, adhesives, and industrial sealant compounds

Noise Level
<70 dB

Features
High Shear Mixing, Automatic Feeding, Uniform Homogenization, User-friendly Interface, Dust-free Operation

Phase
Three Phase

Temperature
Ambient to 180C (with temperature control)

Frequency
50/60 Hz

Type
Automatic Silicon Sealant Making Machine

Material
Stainless Steel, Mild Steel (as required)

Capacity
200 - 2000 Kg/Batch (customizable)

Computerized
Yes

Control Mode
PLC Control Panel

Voltage
380 - 415 V

Power
18 - 40 kW (depending on model)

Weight (kg)
2500 - 5000 kg (model dependent)

Dimension (L*W*H)
4500 mm x 2000 mm x 3200 mm

Color
Industrial Grey / Blue (custom options available)

Hydraulic Power Pack
Included for efficient operation

Production Line Integration
Compatible with automatic packaging & filling systems

Material Feeding
Automatic / Manual Options

Safety Systems
Emergency Stop, Overload Protection, Interlocks

Agitator Motor Type
Explosion-proof (optional)

Mixing Method
High-speed disperser & planetary mixer

Cleaning System
Easy Clean Inbuilt CIP (Clean-In-Place)

Vacuum System
Yes, for bubble-free mixing

Discharge Method
Bottom Discharge with Pneumatic Valve

Silicon Sealant Making Machine Trade Information

FOB Port
yes

Payment Terms
Cash on Delivery (COD), Letter of Credit (L/C), Telegraphic Transfer (T/T), Western Union, Paypal, Cash Against Delivery (CAD), Cash in Advance (CID), Cheque, Cash Advance (CA)

Supply Ability
1000 Per Year

Delivery Time
1 Week

Sample Policy
Free samples available with shipping and taxes paid by the buyer

Packaging Details
PACKING, WOODEN BOX

Main Export Market(s)
Australia, South America, Eastern Europe, Western Europe, Middle East, Central America, Asia, North America, Africa

Main Domestic Market
All India

Certifications
ISO 9001 : 2015

About Silicon Sealant Making Machine

Chemical Industry Resins, Sealant, silicon rubber,glue/ adhesive,paint, dye,BMC/CMC,pigment, plastics, batteries. Tooth paste, Clay etc Food Industry:Bubble gum, dough, chewing gum, soft candy,cheeseetc Pharmaceutical:Certification: CE CertificateDischarge Way: Hydraulic tilt; Screw extruding ,Bottom valve.Heating: Electric heater heating; Circulation oil heating or Steam heating.Material: SUS304/S.S316/Mild steel. Customized according to client?s request.Capacity: 5-3000L

Advanced Mixing Technology

This machine utilizes high-speed dispersers and planetary mixers for thorough and uniform blending. The vacuum system eliminates bubbles, resulting in superior-quality sealants ideal for demanding applications. Its robust process ensures high shear mixing for optimal dispersion of ingredients.

User-Friendly & Automated Operation

With automatic or manual feeding options, a user-friendly PLC control panel, and comprehensive safety features, operators can easily manage the production process. The inbuilt CIP system makes cleaning straightforward, minimizing downtime and supporting sanitary operations.

Versatile Production Capabilities

Designed for flexible production, the machine accommodates various batch sizes and integrates with packaging and filling lines. Customizable to your requirements, it handles stainless or mild steel construction and offers explosion-proof motors for enhanced safety in diverse industrial settings.

FAQ's of Silicon Sealant Making Machine:

Q: How does the Silicon Sealant Making Machine ensure bubble-free mixing?

A: The machine is equipped with a dedicated vacuum system that removes air during the mixing process, preventing bubble formation and resulting in a smooth, homogeneous sealant batch.

Q: What mixing methods does this machine use to achieve uniform product quality?

A: It employs both high-speed disperser and planetary mixer technologies. These methods work together to provide high shear mixing and thorough dispersion of raw materials, ensuring consistent product quality in every batch.

Q: Where can this automatic machine be integrated within a production line?

A: This machine is designed to integrate seamlessly with automatic packaging and filling systems, making it suitable for use in large-scale sealant and adhesive manufacturing lines.

Q: When should the CIP system be used for cleaning the machine?

A: The CIP (Clean-In-Place) system can be utilized after completing each batch or during scheduled maintenance intervals. It streamlines cleaning without disassembling the equipment, maintaining hygiene and reducing production downtime.

Q: What safety features are included to protect operators during use?

A: Safety is ensured through emergency stop functions, overload protection, interlocks, and an optional explosion-proof agitator motor. These features safeguard operators and preserve equipment integrity.

Q: How does the bottom discharge with pneumatic valve improve processing efficiency?

A: The bottom discharge system allows for quick, controlled emptying of the mixed product, minimizing residual waste and optimizing batch turnaround times.

Q: What are the benefits of PLC-controlled automated operation?

A: A PLC control panel simplifies system management, enables precise process adjustments, ensures repeatable results, and provides real-time feedback for operators, enhancing productivity and reliability in manufacturing.
