Skid Cip / Wip System

Get a Price/Quote

Skid Cip / Wip System Specification

Features
Hygienic construction, PLC based operation, CIP/WIP cycle programming, energy efficient, minimal manual intervention, quick installation, easy maintenance

Noise Level
Below 70 dB

Usage & Applications
CIP (Cleaning-In-Place) & WIP (Washing-In-Place) for process tanks, pipelines, and equipment in dairy, food & beverage, pharma, and chemical industries

Phase
Three Phase

Frequency
50 Hz / 60 Hz

Temperature
Ambient to 95C

Type
Skid Mounted CIP/WIP System

Material
Stainless Steel (SS304/SS316)

Capacity
100 LPH to 10,000 LPH (customizable)

Computerized
Yes

Control Mode
Automatic / Semi-Automatic

Voltage
220V / 380V / 415V (as required)

Power
3 kW to 15 kW (depends on system size)

Weight (kg)
As per design (typically 300 kg to 2000 kg)

Dimension (L*W*H)
Customized as per plant layout

Color
Metallic Silver / Polished Steel

Cleaning Media
Hot water, Detergent, Alkali, Acid

Leak Test
Hydrostatic Leak Test provided

Heating Mode
Electric Heater / Steam Heating

Display
Touchscreen HMI (Human Machine Interface)

Surface Finish
Internal Ra 0.4-0.8 m for hygiene

Connection Type
Tri-Clamp/Flanged Ends

Recirculation Time
Adjustable, standard 1030 min per cycle

Flow Rate Control
Variable Frequency Drive (VFD) integrated

Automation Level
Fully Automatic / Semi-Automatic

Installation
Skid Mounted, Ready-to-Use

Pump Type
Centrifugal/Sanitary Pump

Piping
Sanitary Grade Stainless Steel

Tank Volume
60L, 100L, 200L, 500L, 1000L or customized

Documentation
IQ/OQ/PQ support for pharma and regulated industries

Compliance
cGMP, FDA guidelines (as required)

Safety Features
Overheat protection, Emergency stop, Level sensors

Mobility
Movable Skid with Wheel Locks

Number of Tanks
Single/Double/Triple as per requirement

Skid Cip / Wip System Trade Information

FOB Port
yes

Payment Terms
Cash Against Delivery (CAD), Cash on Delivery (COD), Telegraphic Transfer (T/T), Western Union, Paypal, Letter of Credit (L/C), Cash in Advance (CID), Cheque, Cash Advance (CA)

Supply Ability
100 Per Year

Delivery Time
3 Week

Sample Policy
Free samples available with shipping and taxes paid by the buyer

Packaging Details
PACKING, WOODEN BOX

Main Export Market(s)
Australia, North America, South America, Eastern Europe, Western Europe, Middle East, Africa, Central America, Asia

Main Domestic Market
All India

Certifications
ISO 9001 : 2015

About Skid Cip / Wip System

Skid Cip / Wip System

Mobile type Clean In Place / Wash in Place System

Application & Process :

CIP/ WIP system is useful for cleaning and washing at place of Vessel, Tank, Bin, Fluid Bed Equipment, High shear Mixer, Blender, Auto Coater and IBC Bin.Trolley mounted CIP system have inlet connection with pneumatic operated valve for Plain water, Hot water, Detergent and D.M.Water with pressurized pump, which are connected with spraying ball with supply pipe on the machine. The complete CIP/WIP system is operated by PLC controls system with touch screen HMI. PLC controls system is working as per set time for washing cycle of the inlet & outlet as per requirements.Trolley mounted complete CIP/WIP system is consist of High pressure pump, Inlet Connection pneumatic valve , Outlet connection with pneumatic Valve, Pneumatic control panel, Eelctric controls panel with PLC & HMI Touch screen. CIP/WIP system can be supply with liquid detergent tank, Hot water generator etc. as per customer requirements.
Skid Type CIP / WIP / Washing System Mobile type Clean In Place / Wash in Place System

Application & Process :

CIP/ WIP system is useful for cleaning and washing at place of Vessel, Tank, Bin, Fluid Bed Equipment, High shear Mixer, Blender, Auto Coater and IBC Bin.We manufacture skid type of CIP/ WIP system with trolley Mounted CIP system with controls.Trolley mounted CIP system have inlet connection with pneumatic operated valve for Plain water, Hot water, Detergent and D.M.Water with pressurized pump, which are connected with spraying ball with supply pipe on the machine. The complete CIP/WIP system is operated by PLC controls system with touch screen HMI. PLC controls system is working as per set time for washing cycle of the inlet & outlet as per requirements.Trolley mounted complete CIP/WIP system is consist of High pressure pump, Inlet Connection pneumatic valve , Outlet connection with pneumatic Valve, Pneumatic control panel, Electric controls panel with PLC & HMI Touch screen. CIP/WIP system can be supply with liquid detergent tank, Hot water generator etc. as per customer requirements.

Salient Features :

Design is cGMP - Current Good Manufacturing Practices compliance. All contact parts AISI 316 /316L & non contact parts AISI 304. CIP (Cleaning-In-Place) is a system designed for automatic cleaning by Plain water, Hot Water, detergent, D.M.Water and rinse solutions without major disassembly and assembly work. Mobile type CIP/WIP system so can be wash HSMG, FBD, Vessels, Tank, Auto coater & Bin etc. Capacity is designed to accordingly as per customer requirement The Clean-In-Place Systems can be provide reservoirs for detergent and rinse solutions as well as pumping and heating capabilities for the solutions. The washing process consists of several cycles in which rinsing material is recycled through the vessels, pumps, valves and other process equipment in the flow system. The cleaning can be carried out with automated or manual systems is a reliable process that meets the stringent hygiene regulations demanded by the food, dairy, beverage, biotechnology and pharmaceutical industries etc. All the operation processes take place in sealed pipe line, which is easy to operate saving work and meets high sanitary requirement. It has advantages as energy-saving, high work efficiency, perfect cleaning effect, operator safety and easy to operate and maintain.
Skid type CIP/WIP System with PLC Controls & 150 Liter Hot water generator

Hygienic and Versatile Skid CIP/WIP System

Engineered to deliver thorough cleaning for process tanks, pipelines, and equipment, the system supports customizable tank volumes and pump capacities. Its sanitary-grade stainless steel construction and Ra 0.4-0.8 m internal finish maintain stringent hygiene standards necessary in regulated industries. Programming via PLC allows adaptive cycles, while the movable skid provides flexibility on the production floor.

User-Friendly Automation with Touchscreen Control

Featuring a touchscreen HMI panel, the system offers intuitive control over cleaning cycles, temperature settings, and flow rates with VFD integration. Automation levels can be tailored, enabling fully automated or semi-automatic operation to match plant requirements. Safety is prioritized with level sensors, emergency stop, and overheat protection.

Reliable Compliance and Quality Assurance

This system meets cGMP and FDA guidelines, ensuring suitability for pharmaceutical and food applications. Documentation support for IQ/OQ/PQ is provided, catering to the needs of highly regulated industries. Each unit undergoes hydrostatic leak testing and is supplied with customizable installation dimensions for seamless plant integration.

FAQ's of Skid Cip / Wip System:

Q: How does the Skid CIP/WIP System operate for cleaning and washing applications?

A: The system utilizes centrifugal sanitary pumps to circulate cleaning media such as hot water, detergents, alkalis, or acids through process equipment. Automated or semi-automatic cycles can be programmed via the PLC-based control panel, with recirculation time and flow rate easily adjustable to ensure effective cleaning.

Q: What are the benefits of using a skid-mounted, ready-to-use CIP/WIP system?

A: The skid-mounted design enables quick installation and operational readiness, minimizing plant downtime. Mobility features, including wheel locks, allow easy repositioning, and the integrated controls ensure streamlined cleaning with minimal manual intervention, enhancing productivity and hygiene standards.

Q: When is electric heater or steam heating used for the cleaning process?

A: Either electric heaters or steam heating can be selected based on plant infrastructure and cleaning requirements. Electric heating is suited for precise temperature control, while steam heating can provide rapid and energy-efficient temperature elevation, particularly for large tank volumes.

Q: Where is the Skid CIP/WIP System most commonly applied?

A: The system is widely used in dairy, food & beverage, pharmaceutical, and chemical industries for cleaning process tanks, piping, and machinery. Its compliance with cGMP and FDA guidelines makes it particularly suitable for regulated environments demanding stringent hygiene.

Q: What customization options are available for tank volume, capacity, and installation dimensions?

A: Tanks can be configured in 60L, 100L, 200L, 500L, 1000L sizes, or tailored to specific requirements. Flow rates and dimensions are fully customizable to align with plant layout and process needs. The system's versatility covers a wide range of capacities, from 100 LPH up to 10,000 LPH.

Q: How does the touch screen HMI and PLC-based automation benefit system usage?

A: The touchscreen HMI allows operators to easily manage cleaning cycles, temperatures, and flow rates. Integrated PLC automation reduces manual tasks, improves cycle consistency, and provides comprehensive data logging for quality assurance and regulatory documentation.

Q: What safety and compliance features are incorporated?

A: Safety measures include overheat protection, emergency stop buttons, and level sensors to prevent operational hazards. Compliance with cGMP and FDA guidelines is ensured, and full documentation (IQ/OQ/PQ) is provided to meet pharmaceutical and food industry standards.
