Vacuum Paddle Mixer Dryer

Vacuum Paddle Mixer Dryer

LOW TEMPERATURE VACUUMIZED DRYING PROCESS TECHNIC

Application & Process :

The Vacuum Paddle Mixer Dryer is suitable for mixing and drying the material which can not operate at low Temperature easily oxidized, poisonous in nature. It operates at low Temperature efficiently under vacuum. It is used for raw materials drying and mixing powder or granules of Pharmaceutical Materials, Crystalline, Insecticides, Pesticides, and Food industry and heat sensitive products.

• Material that cannot undertake high temperature.
• Material that is easy to oxidize.
• Material that do not permit to destruct.
• To recover material with residual volatile.
• Material with vigorous irritative and toxicity

The Vacuum Paddle Mixer Dryer consists of a jacketed cylindrical shell with rotating with specially designed Paddle Agitator type blade by rigid fabricated structure motor, gear box. There is provision for application of vacuumized inside the shell and circulation of heating media in the jacket during the rotation of the stirrer. The large heating surface area presented by the internals surface of the shell ensures uniform drying of the product, as the product gently moving & fluidized while the Paddle stirrer rotates. The diffusive action induced by the mixing stirrer constantly presents a fresh layer to come into contact with the indirectly heated walls of the shell. A well designed sealing system enable maintenance of deep vacuum inside the shell, and also ensures positive circulation of a heating media in the jacket.

Salient Features :

• Design is cGMP- Current Good Manufacturing Practices compliance.
• All contact parts AISI 316 & non contact parts AISI 304.
• Continuous rotation of paddle stirrer, material will make continuous movement and fluidized in the container and reach to uniform mixing and drying at low temperature..
• Very low value of final moisture even at low drying temperatures.
• Option for two type design of shell 1. Cylindrical type and 2. "U" shape.
• Continues vacuum maintenance during process.
• Vacuumized closed system with condenser, Receiver for solvent recovery &

Optional Features :Option for two type designed of shell 1. Cylindrical type and 2."U" shape.
